Polyol selection is the first decision in a polyurethane formulation, and the one that is hardest to reverse. If a production line is later changed from a polyester to a polyether backbone, the technical team usually has to revisit mix ratio, catalyst loading, tank temperature, gear-pump sizing, and the degassing sequence. The polyol is not just a hydroxyl source; it supplies the soft segment, much of the molecular weight, the network functionality, and the viscosity the metering system must handle [1]. When someone asks for a formulation change with the same machine settings, they are asking two materials to behave identically even though their backbones respond differently to moisture, shear, and temperature.
What a Polyol Actually Controls in a Polyurethane System
A polyol is a molecule, or a blend of molecules, with two or more hydroxyl groups. It reacts with an isocyanate through the NCO group to form the urethane linkage [2]. The average number of hydroxyl groups per molecule is functionality; molecular weight divided by functionality gives equivalent weight, which determines how much isocyanate is required. A high-functionality, low-molecular-weight polyol creates a shorter, more tightly crosslinked network, while a long-chain difunctional polyol creates a more elastic system. The backbone between the hydroxyl groups — ether, ester, carbonate, or caprolactone — controls hydrolysis, oxidation, and mechanical behavior [1].
The Two Workhorse Families: Polyether and Polyester Polyols
Most production polyurethanes are built on one of two families: polyether polyols or polyester polyols.
Polyether Polyols
Polyether polyols are produced by adding propylene oxide and sometimes ethylene oxide to a multifunctional initiator such as glycerin, sorbitol, or sucrose. The ether backbone gives good hydrolytic stability and low-temperature flexibility, and the propylene oxide/ethylene oxide ratio controls hydrophilicity and reactivity [3]. They are the default for flexible slabstock foam, molded seating, rigid foam insulation, sealants, and many hydrolysis-prone elastomer applications. Compared with ester-based systems, polyether formulations generally have lower viscosity at a given molecular weight and often a lower raw-material cost [1], [3].
Polyester Polyols
Polyester polyols are usually condensation products of glycols and dicarboxylic acids — adipic, phthalic, or succinic acid, or recovered PET fractions. The ester linkage is more polar and forms stronger intermolecular hydrogen bonds, so polyester polyurethanes typically deliver higher tensile strength, abrasion resistance, cut/tear resistance, and better adhesion to fabric, leather, and metal. The trade-off is hydrolytic stability: in warm, humid service, ester linkages can cleave back to acid and alcohol [1], [2]. Polyester systems are common in shoe soles, coatings, casting elastomers, printing rollers, and parts that need a combination of high abrasion resistance and predictable hardness.
Semi-rigid foam formulations often sit between these two families. A long-chain polyether with moderate branching can produce the required support and recovery, while a low-functionality polyester can raise tear strength but narrow the processing window.
Semi-rigid foam formulations sit between flexible and rigid networks, so polyol backbone and functionality decide cell opening, hardness recovery, and the mixing window. What Is Semi Rigid Polyurethane Foam covers what that middle hardness range means for production.
Hardness is not a property you choose at the end. It is partly set by the polyol molecular weight, its functionality, and the chain extender level. A Shore A reading will not transfer cleanly to a Shore D target because the two scales use different indenter geometries and apply to different hardness regions.
When a formulation changes from a high-molecular-weight polyether to a short-chain polyester, the durometer can move even if the isocyanate index stays constant. Shore A Vs Shore D Hardness In Polyurethane covers the test difference and where each scale is reliable.
High-Performance Specialty Polyols
Where cost is secondary and dynamic load, oil contact, or long-term water exposure dominates, formulators move to specialty backbones. The main options are PTMEG, polycaprolactone polyols, and polycarbonate polyols.
- PTMEG polyols are polymerized from tetrahydrofuran. They combine polyether hydrolysis resistance with excellent resilience, dynamic performance, and low-temperature flexibility; typical uses include high-end elastomer wheels, rollers, and dynamic seals [2].
- Polycaprolactone polyols are produced by ring-opening polymerization of caprolactone. They keep ester-type tensile and abrasion performance while offering better hydrolysis resistance than standard adipate polyesters.
- Polycarbonate polyols carry a carbonate backbone that gives the strongest hydrolytic and oxidative stability of the group, at the highest price. They are used in premium elastomers and coatings where failure is more expensive than the raw material.
Other systems include polybutadiene polyols for low-temperature and high-elongation applications, natural oil polyols such as castor-oil derivatives, and filled or copolymer polyols used to raise hardness and load-bearing in flexible foam. These do not replace polyether or polyester across the board; they solve specific failure modes.
Polyol Specification Values That Change the Machine Setup
Four values on a polyol TDS usually predict how the material will behave on the production floor:
- Hydroxyl value, expressed in mg KOH/g, sets equivalent weight and therefore mix ratio. Hydroxyl value is determined by ISO 14900 [4].
- Viscosity, stated at a defined temperature, determines whether the metering pump, tank agitator, and mix head can move the material without cavitation or pressure spikes.
- Acid number, measured as mg KOH/g for polyether or polyester polyols, indicates residual acidity that can slow catalyst activity or accelerate polyester hydrolysis [5].
- Moisture content consumes isocyanate, generates carbon dioxide during reaction, and can cause pinholes, density scatter, and soft spots. A polyol stored in a partly open drum will take on moisture, and the effect is not visible at room temperature.
- Unsaturation in polyether polyols also matters in high-resilience and specialty elastomers; high unsaturation lowers the effective functionality of the network [1].
For flexible foam and seating grades, resilience is often built into the polyol more than into the blowing package. Ethylene oxide content, molecular weight distribution, and functionality all shift how the cell walls recover after compression.
Resilience testing often exposes polyol-side differences that a simple density check misses. Measuring Polyurethane Foam Resilience A Practical Test Guide covers the test setup, typical acceptance limits, and what a low rebound value tells you about the network.
How Polyol Choice Appears on the Pouring Machine
The same polyol can run cleanly on one machine and cavitate on another if viscosity and temperature are not matched. Polyether polyols typically process in a lower temperature band than polyester polyols. A machine set up for a low-viscosity polyether may need higher tank temperatures, larger gear-pump clearances, or a different mix-head speed for a filled polyester. Fillers and high-viscosity additives make the gap larger.
Moisture management is also a machine function. Many casting and elastomer lines include vacuum degassing to remove dissolved water and entrained air. If the polyol is moisture-sensitive or the foam density must be tightly controlled, the degassing step is not optional. On equipment with vacuum degassing rated below -0.095 MPa, polyester and PTMEG systems can be degassed effectively before metering.
For example, a polyester-based roller casting formulation with a MOCA chain extender often arrives at the machine with the B-side held in a different temperature band than the polyol side. A 2A2B casting unit separates the prepolymer and chain extender circuits so that degassing, heating, and metering do not compete for the same process window.
Need Help Matching a Polyol System to Your Pouring Line?
If you are switching polyol families, introducing a filled system, or struggling with density drift, send the polyol TDS and your current batch size to Info@chinahaifeng.com or WhatsApp: 86 13566296633. Include tank temperature, mixing-head speed, and target cycle time. The engineering review is based on the material data and your existing line, not on a generic equipment list.
Choosing the Right Polyol: A Decision Framework
Work through the following questions in order.
- Define the service environment. Is the part exposed to water, humid air, oil, dynamic flexing, UV, or wide temperature swings? This alone often eliminates one family.
- Set the mechanical targets. Hardness, tensile, tear, resilience, and compression set. A polyester may win on tensile and abrasion; a polyether may win on hydrolysis and low-temperature flexibility.
- Check the processing window. Viscosity at process temperature, pot life, moisture sensitivity, and required degassing. A polyol that gives the right properties but cannot be metered consistently is not a production solution.
- Validate with a trial before retooling. A deviation of one percentage point in the component ratio can shift final foam density by more than 3 kg/m³, so formulation changes should be followed by a small batch on the actual machine rather than a tabletop beaker test.
Talk to a Polyurethane Equipment Engineer
If the correct polyol for the application is already identified but the line cannot handle its viscosity, moisture sensitivity, or cycle-time requirements, the next step is to review how the metering and mixing system is matched. Haifeng supplies low-pressure and high-pressure foaming machines, elastomer casting units, and turnkey production lines that process polyether, polyester, PTMEG, polycaprolactone, and filled polyol systems. For a specific machine or line recommendation, send the following:
- Polyol and isocyanate TDS with hydroxyl value, NCO content, and viscosity curves
- Required output per shift or mold cycle
- Current mold temperature and part geometry
- Current pain point: density drift, pinholes, hydrolysis, or mix-ratio error
You can reach the engineering team at Info@chinahaifeng.com or on WhatsApp: 86 13566296633.
Frequently Asked Questions
What is the main difference between polyether and polyester polyols?
Polyether polyols have an ether backbone that resists hydrolysis and remains flexible at low temperature. Polyester polyols have a more polar ester backbone that provides higher tensile, abrasion, and adhesion but is more sensitive to warm, humid service [1], [3].
Which polyol is best for polyurethane shoe soles?
Most mid-range PU soles use polyester polyols because the ester linkage improves abrasion resistance, cut growth, and adhesion to the shoe upper. For hydrolytic stability — especially in wet-service or outdoor soles — formulators may switch to polyether or PTMEG-based systems and accept some trade-off in tensile strength.
How does hydroxyl value change the mixing ratio?
Hydroxyl value determines equivalent weight: equivalent weight = 56,100 ÷ hydroxyl value. A lower hydroxyl value means a higher equivalent weight and less isocyanate demand per kilogram; a higher hydroxyl value means more isocyanate is required to maintain the target index [4].
Can I switch from polyester to polyether on the same pouring machine?
Possibly, but not without checking viscosity, tank temperature, degassing, and gear-pump performance. Polyester systems often require higher processing temperatures, so a machine set for polyether may need a warm-up period, speed adjustments, or pump changes.
What moisture level is acceptable in a polyol?
The level depends on the formulation and whether the machine has vacuum degassing. In moisture-sensitive cast elastomer or microcellular systems, even a few hundred ppm can change void content and density. Production lines commonly degas polyol blends before metering to keep moisture and dissolved air from entering the mix head.
What is PTMEG used for?
PTMEG is used in premium polyurethane elastomers — rollers, wheels, seals, and dynamic parts — where high resilience, hydrolytic stability, and low-temperature flexibility justify the higher raw-material cost [2].
References
[1] M. Ionescu, Chemistry and Technology of Polyols for Polyurethanes, 2nd ed. Shawbury, UK: Smithers Rapra Technology, 2016.
[2] G. Oertel, Polyurethane Handbook: Chemistry, Raw Materials, Processing, Application, Properties, 2nd ed. Munich, Germany: Hanser Publishers, 1994.
[3] M. Szycher, Szycher’s Handbook of Polyurethanes, 2nd ed. Boca Raton, FL, USA: CRC Press, 2012.
[4] ISO 14900:2017, Plastics — Polyols for use in the production of polyurethane — Determination of hydroxyl number, International Organization for Standardization, Geneva, Switzerland, 2017.
[5] ASTM D7253-16, Standard Test Method for Polyurethane Raw Materials: Determination of Acidity as Acid Number for Polyether Polyols, ASTM International, West Conshohocken, PA, USA, 2016.
