PU Foam Cutting and Slicing Equipment | Foam Blocks
Haifeng supplies PU foam cutting equipment for slabstock blocks, with synchronized cut-off and configurable slicing or CNC contour modules for furniture padding.
Equipment Role
Slabstock block cutting and optional downstream finishing
Reference Model
HF-CUT-AUTO synchronous traveling bandknife cutter
Cut Length
1.0–30.0 m reference configuration
Cutting Tolerance
±2.0 mm reference configuration
Product Overview
Haifeng supplies PU foam cutting equipment for slabstock blocks, with synchronized cut-off and configurable slicing or CNC contour modules for furniture padding.
Haifeng foam cutting auxiliary equipment connects flexible slabstock production to furniture foam finishing. The reference HF-CUT-AUTO unit is a synchronous traveling bandknife cutter deployed with the continuous flat-top sofa-cushion line in Brazil. It tracks the moving block and makes transverse cuts without stopping the foaming conveyor.
The supplied configuration specifies 1.0–30.0 m cut lengths and ±2.0 mm cutting tolerance. The Brazil project used 2.4 m and 3.0 m block lengths. These data describe the synchronous cut-off configuration; they are not the accuracy or working envelope of every optional cutting module.
For downstream production, Haifeng can integrate horizontal circular slicing and CNC contour cutting. Select those modules from the required block dimensions, sheet thickness, finished shape, order mix and curing schedule. Model, working envelope and contour/slicing accuracy are established for the selected module.
The equipment is supplied with on-site installation, commissioning and operator training, a 1-year comprehensive machine warranty, long-term spare parts and remote control-system support.
Production Workflow
Define Block and Finished-Part Geometry
Specify block dimensions, target cut lengths and any downstream sheet or contour requirements.
Track and Cut the Moving Foam Block
Synchronize the traveling cut-off unit with the continuous conveyor and execute square transverse cuts.
Transfer and Cure
Coordinate block transfer and the curing schedule before downstream cutting.
Configure Slicing or Contour Finishing
Integrate optional horizontal slicing or CNC contour modules for the selected product geometry.
Technical Specifications
Reference configuration based on the supplied furniture production brief. Optional modules are selected for the required block dimensions, cutting geometry and production schedule.
| Technical Parameter | HF-CUT-AUTO (synchronous traveling cut-off) |
|---|---|
| Equipment Role | Slabstock block cutting and optional downstream finishing |
| Reference Model | HF-CUT-AUTO synchronous traveling bandknife cutter |
| Cut Length | 1.0–30.0 m reference configuration |
| Cutting Tolerance | ±2.0 mm reference configuration |
| Reference Project Cuts | 2.4 m and 3.0 m block lengths in the Brazil sofa-cushion project |
| Production Interface | Synchronous tracking with the continuous foaming conveyor |
| Optional Modules | Horizontal circular slicing and CNC contour cutting; application-specific configuration |
| Suitable Applications | Sofa cushions, mattress foam and furniture padding |
| Curing Coordination | Route blocks through the agreed curing stage before downstream finishing |
| Warranty | 1-year comprehensive machine warranty |
Key Features
Synchronous Cut-Off
Travel with the moving slabstock block during the transverse cut.
Defined Cutting Configuration
Apply the stated length and tolerance to the reference cut-off unit.
Optional Horizontal Slicing
Integrate slicing around the required foam sheet thickness and block envelope.
Optional CNC Contour Integration
Specify finishing modules for furniture cushion and padding shapes.
