Marine Steel Structure Polyurea Solution
Diesel-powered two-component spray equipment with heated delivery and configured elevation interfaces for a selected marine steel coating system.
Extreme Weatherable Protection for Sea-Crossing Bridges & Offshore Steel
Diesel-powered two-component spray equipment with heated delivery and configured elevation interfaces for a selected marine steel coating system. The package covers a diesel-powered hydraulic spray skid, heated hoses, the specified gun and pressure-relief interfaces, and controls. Enclosure and access-platform accessories are optional. Coating materials are supplied separately; blasting equipment and fuel are customer interfaces. Hazardous-area suitability, generator placement, load and delivery configuration require project-specific documentation.
Onboard Power Interface
The specified diesel/generator package is matched to the complete electrical load and site placement.
Elevated Delivery Configuration
Total hose length is separate from vertical lift; gun-end pressure and temperature require operating records.
Select the equipment, coating build-up and inspection plan against the substrate, part geometry, production target and site conditions. Material qualification and reported outcomes require project-specific records.
Turnkey Marine Steel Protective Coating Workflow
A configured sequence of substrate preparation, material conditioning, application, cure and inspection for the selected coating system.
Steel Grit Blasting & Profile Inspection
Steel plate surfaces are grit-blasted to ISO 8501-1 Sa 2.5 cleanliness with an anchor pattern profile of 60 to 80 µm to ensure mechanical keying.
Moisture-Tolerant Epoxy Primer Application
Apply the selected corrosion-protection primer to the prepared steel using the agreed build-up. Primer compatibility, application window and recoat conditions are confirmed with the coating supplier.
Autonomous Heating & High-Elevation Pumping
The onboard 40 kW diesel generator powers primary heaters, raising materials to 70°C and pumping fluids at 21 MPa up 60-meter vertical hoses.
Reference Solution Engineering Envelope
Supplied configuration and coating-system references. Values depend on the stated material, substrate, test and operating conditions; original records are not attached.
| Parameter | Value / Unit | Applicable Configuration / Conditions |
|---|---|---|
| Continuous Spray Fluid Pressure | 16.0 to 21.0 MPa | Heavy-duty coaxial hydraulic proportioner |
| Maximum Spray Flow Output | 2.5 to 11.0 kg/min | Continuous rate matching manual and robotic spray guns |
| Autonomous Electrical Power | 40 kW Onboard Diesel Generator | Three-phase 380V 50Hz ; engine configuration and certification documents require verification |
| Maximum Vertical Lift Reach | Up to 60 meters | Insulated copper-mesh wrapped heated umbilical line |
| Neutral Salt Spray Durability | Greater than 8,000 hours | ASTM B117 testing with zero blistering or rust; supplied material/test result requires original specimen, method and report |
| Accelerated UV Weathering | Greater than 5,000 hours | QUV-A cycle testing on aliphatic aspartic topcoat; supplied material/test result requires original specimen, method and report |
Core Equipment for This Solution
The package covers a diesel-powered hydraulic spray skid, heated hoses, the specified gun and pressure-relief interfaces, and controls. Enclosure and access-platform accessories are optional. Coating materials are supplied separately; blasting equipment and fuel are customer interfaces. Hazardous-area suitability, generator placement, load and delivery configuration require project-specific documentation.
Core Advantages of Haifeng Marine Solutions
Configured process mechanisms and project interfaces for the selected equipment package.
Onboard Power Interface
The specified diesel/generator package is matched to the complete electrical load and site placement.
Elevated Delivery Configuration
Total hose length is separate from vertical lift; gun-end pressure and temperature require operating records.
Configured Pressure Controls
Relief, hoses and controls are selected and verified as a complete system; response claims require original tests.
Material-System Qualification
Salt-spray and UV performance belong to the selected primer, membrane and topcoat system, not the spray machine alone.
Related Project Draft
Review the project configuration described in the supplied brief. Project records and reported results require verification before public use.
Frequently Asked Questions
Find answers about Marine Steel Structure Polyurea Solution, including material selection, equipment configuration and the information needed to plan a production line.
How are onboard power and elevated spraying configured?
How are humidity and surface conditions handled?
What establishes hazardous-area and pressure-control suitability?
Do accelerated corrosion tests predict coating service life?
Request a Marine Bridge Protective Coating Proposal
Share the substrate or finished part, selected materials, coating and quality requirements, target output, automation needs and factory or worksite conditions.
